4 digit 7 Segment Led Display , Common Cathode Seven Segment Display Green 0.56 inch

Name: 4 digit 7 Segment Led Display Common Cathode Seven Segment Display Green 056 inch
Brand: LIGHTBO
Price: 1 USD

China 4 digit 7 Segment Led Display , Common Cathode Seven Segment Display Green 0.56 inch factory

Brand Name : LIGHTBO

Model Number : LB40561LJ1B

Certification : RoHS&SGS&ISO

Place of Origin : Shenzhen,China

MOQ : 1000PCS

Price : negotiable

Payment Terms : TT in advance& Western Union

Supply Ability : 50000PCS/Day

Delivery Time : 10-15Days

Packaging Details : EPE+CARTON

Digit height : 0.56 inches (14.2mm)

Dimensions : 50.3 x 19 x 8mm

Polarity : Common cathode

Colour : Super bright GREEN

Surface : White segments, black/grey face

Contact Now

4X7 Segment Led Display Common Cathode Seven Segment Display Green 0.56"

Description:

4 digit 0.56-inch common cathode yellow green 7 segment LED display
Digit height: 0.56 inches (14.2mm)
Dimensions: 50.3 x 19 x 8mm
Polarity: common cathode
Emitting colors: available in red, blue, white, pure green, pure white, amber, yellow green and orange

Absolute Maiximum Rating (Ta=25℃)

Parameter	Symbol	Ratings	Unit
Forward Current(per dice)	Ipm	20	mA
Reverse Voltage(per dice)	Vr	5	V
Power Dissipation(per dice)	Pm	80	mW
Operating Temperature Range	Topr	-40～+85	℃
Storage Temperature Range	Tstg	-40～+85	℃
Solder Temperature(3 sec)	Th	260	℃

Code:J-Ultra Bright Green

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage(Per dice)	Vf	If=20mA	1.8		2.5	V
Reverse Voltage(Per dice)	Vr	Ir=10uA		5		V
Luminous Intensty(Per dice)	Iv	If=20mA	40		50	mcd
Spectrum With Of Half Value	△	If=20mA		30		nm
Wavelength	D	If=20mA	569		573	nm
Peak Forward Current(Per dice)1/10 Duty Cycle,0.1ms Pulse	Ifp	70				mA
Operating Temperature Range	Torp	-35℃～+85℃
Storage Temperature Range	Tstg	-35℃～+85℃
SolderTemperature 1.5mm below seating plane for 3 Seconds at 260℃
Absolute Maximum Rating at Ta=25℃

Feature:

High luminous intensity
Low power consumption
Extremely low current
Stable performance
Big viewing angle

Stable performance

Easy assembly

IC Compatible
Long lifetime
Meet RoHS Compliant

Application ;

home appliances, set up boxes, isntrument panels,digital indicators

Product Picture:

4 digit 7 Segment Led Display , Common Cathode Seven Segment Display Green 0.56 inch

Product Tags:

seven segment led display

low power 7 segment display

4 digit 7 Segment Led Display , Common Cathode Seven Segment Display Green 0.56 inch Images
